JCC JC040045 Toughbay 200W 120° 5700K IP65 Non-Dimmable

Part: JC040045
Need this part urgently: we advise you to check the stock availability for this item by contacting our sales team on 01482 589015
Description
Downloads

Our high performance Led Highbay is available with 120° beam angle, emergency and microwave on/off variants and 2m flex for greater flexibility when installing, IP5 with an IK10 rating and is suitable for extreme operating temperatures -30° to +45°.

  • 120º beam angle
  • Non-dimmable
  • Comes pre-wired with 2m flex
  • Emergency options available
  • M/W on/off options available
  • IP65 & IK10 rated for harsh environments
  • -30º to +45º operating temperature

Mounting method :Pendant
Protection class :I
Outer diameter :239mm
Connection type :Screwless terminal
Housing colour :Black
Voltage type :AC
Control gear :LED driver constant current
Colour rendering index (CRI/Ra) :80-89
Number of poles :3
Height/depth :171mm
Housing material :Aluminium
Light source type :LED non-replaceable
Suitable for emergency lighting :No
Light sharing :Symmetric
Impact resistance (IK rating) :IK10
Nominal voltage :200 to 240V
Degree of protection (IP rating) :IP65
Lamp included :Yes
Control gear included :Yes
Beam angle :Extreme wide beam >80°
Maximum system power :200W
Rated luminous flux acc. IEC 62722-2-1 :24000Lm
Colour of light :White
Type of cabling :Ending
Rated ambient temperature acc. IEC62722-2-1 :-30 to 45°C
Dimming 0-10 V :No
Dimming 1-10 V :No
Dimming DALI :No
Dimming DMX :No
Dimming potentiometer (integrated) :No
Dimming LineSwitch :No
Dimming manufacturer's proprietary system :No
Dimming mains voltage modulation :No
Dimming trailing edge :No
Dimming leading edge :No
Dimming programmable :No
Dimming RF :No
Dimming Sine Wave Reduction :No
Dimming Touch and Dim :No
Dimming Zigbee :No
Dimming with push-button :No
Light distribution :Diffuser
Dimming DSI :No
Power factor :0.95
