JCC JC23401EMWOP RadiaLED Utility Mains IP65 Ø205mm Bulkhead 12W 4000K 700m LED Opal EM

Part: JC23401EMWOP

Need this part urgently: we advise you to check the stock availability for this item by contacting our sales team on 01482 589015

Description

Downloads

IP65 weather resistant, Anti-vandal construction. Corrosion resistant suitable for coastal locations. Opal or prismatic polycarbonate diffuser options, dusk to dawn on/off photocell, emergency, dimmable options available. With up to 95 lumens per circuit Watt.

IP65 weather resistant
Anti-vandal construction
Corrosion resistant
suitable for coastal locations
Opal or prismatic polycarbonate diffuser options
Dusk to dawn on/off photocell options available
Up to 95 lumens per circuit Watt

Mounting method :	Wall surface mounted / ceiling surface mounting
Protection class :	I
Outer diameter :	203mm
Function :	Escape route lighting
Connection type :	Screw connection
Housing colour :	White
Voltage type :	AC
Power supply system :	Peripheral (individual battery)
Control gear :	LED driver constant current
Number of poles :	4
Length :	85mm
Housing material :	Plastic
Light source type :	LED non-replaceable
Cover material :	Plastic opal
Battery chemistry :	NiMH
Nominal voltage :	220 to 240V
Degree of protection (IP rating) :	IP65
Lamp included :	Yes
With remote switch connection :	No
Monitoring equipment :	Other
Colour temperature :	4000K
Maximum system power :	12W
Rated luminous flux acc. IEC 62722-2-1 :	700Lm
Type of cabling :	Suitable for through wiring
Rated ambient temperature acc. IEC62722-2-1 :	0 to 25°C
Light distribution :	Diffuser
Nominal operation time :	0 to 3 Hour
Power factor :	0.9
